Tenda W330R User Manual

Wireless-N Broadband Router
Static Route
Static Route is set by
administrator in advance
is called static route.
Usually, it is set according
to network configuration
when installing the
operation system. It would
not be changed according
to network structure’s
change.
Destination LAN IP: The
address of the remote host
with which you want to
construct a static route.
Subnet Mask:The
network portion of the
Destination LAN IP.
Gateway: The gateway of
the next hop.
76

Tenda W330R Specifications

General

Bandwidth	2.4 GHz
Input voltage	110 - 240 V
xDSL connection	No
Power requirements	AC 9 V, 1.2 A
Networking features	Ethernet, Fast Ethernet, Gigabit Ethernet, WLAN
Ethernet LAN	Yes
Receiver sensitivity	270M: -70dBm@10% PER; 130M: -70dBm@10% PER; 108M: -70dBm@10% PER; 54M: -73dBm@10% PER; 11M: -85dBm@8% PER; 6M: -88dBm@10% PER; 1M: -90dBm@8%
Antenna gain level (max)	2.5 dBi
Ethernet LAN (RJ-45) ports	4
Power consumption (typical)	6 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
