O PERATING M ANUAL DAF380 P RODUCT D ESCRIPTION
ThyssenKrupp Aufzugswerke GmbH
2. Product Description
2.1 Description
Illustration without rope guard
Item Part designation Item Part designation
1 Brake disc 8 Pressure piece
2 Disc on motor shaft 9 Brake test switch
3 Traction sheave 10 Terminal box
4 Compression spring 11 Tightening screw
5 Double-vane magnet 12 Housing
6 Brake release lever 13 Brake block
7 Forced ventilation 14 Grease overflow pipe
Versions
The following versions can be supplied:
1. Groove profiles of the traction sheave
2. Machine base frame versions
3. Safety-relevant accessory parts
Fig. 2.1
4
8
3
6
1
7
9
2
5
11
10
12
13
14
11
08-2011
