O
PERATING
M
ANUAL
DAF380
T
ECHNOLOGY
ThyssenKrupp Aufzugswerke GmbH
3. Technology
3.1 Technical data
Other technical data can be found on the type plate.
If the braking device of the DAF380 is to be used as a protective device
against overspeed for the upward moving elevator car, the brake must
be triggered in the event of overspeed via the electric safety device of the
speed governor or a device with a similar high level of safety that is also
subject to type approval.
In the connection, the requirements, range of application and conditions
stated in the Appendix of Type Test Certificate No. ABV 502/1 are to be
complied with. See Appendix.
DAF380
Diameter of rope pulley
[mm] 540
Permitted radial axle load
[kN] max. 150
Diameter of traction sheave - DT [mm] 560
Permissible shaft load of traction
sheave
[kN] 190
Max. braking torque
[Nm] 2x1400
Type test certificate for brake
ABV502/1
Total machine weight [kg] 1500
Type of machine protection IP21
Table 3.1.1
