Toro 03678 User Manual

2
AdjustingtheControl-Arm
Position
NoPartsRequired
Procedure
Thecontrol-armpositioncanbeadjustedforyour
comfort.
1.Loosenthe2boltssecuringthecontrolarmto
theretainingbracket(Figure3).
g004152
Figure3
1.Controlarm3.Bolts(2)
2.Retainingbrackets
2.Rotatethecontrolarmtothedesiredposition
andtightenthe2bolts.
3
InstallingtheCuttingUnits
Partsneededforthisprocedure:
1
Rightfronthoseguide
1
Leftfronthoseguide
PreparingtheMachine
1.Removethereelmotorsfromtheshipping
brackets.
2.Removeanddiscardtheshippingbrackets.
3.Ateachcuttingunitliftarm,removethelynchpin
thatsecuresthecaptotheliftarmpivotyoke,
andremovethecap(Figure4).
g003975
Figure4
1.Lynchpin
2.Cap
PreparingtheCuttingUnits
1.Removethecuttingunitsfromthecartons.
2.Assembleandadjustasdescribedinthecutting
unitOperator'sManual.
3.Makesurethatthecounterweight(Figure5)is
installedattheproperendofthecuttingunitas
describedinthecuttingunitOperator'sManual.
