g378285

Figure93

1.Cap(coolantreservoir)

2.Hotengine-coolantmark

3.Coldengine-coolantmark

4.Ifthecoolantlevelislow,removethe

coolant-reservoircapandaddthespecied

coolantuntilthelevelitisatthecoldmark(fora

coldengine)orhotmark(forahotengine).

Note:Donotoverlltheexpansiontankwith

coolant.

5.Installthecoolant-reservoircap.

6.Closeandlatchthehood;refertoClosingthe

Hood(page40).

RemovingDebrisfromthe

CoolingSystem

ServiceInterval:Beforeeachuseordaily(More

frequentlyindirtyoperating

conditions).

Every100hours—Inspectthecoolingsystem

hoses.

Every2years—Flushandreplacethecooling

systemuid.

1.Preparethemachineformaintenance;referto

PreparingforMaintenance(page40).

2.Openthehood;refertoOpeningtheHood(page

40).

3.Thoroughlycleanalldebrisoutoftheengine

area.

4.Closeandlatchthehood;refertoClosingthe

Hood(page40).

5.Unlatchtherearscreenandpivotitopen(Figure

94).

g004138

Figure94

1.Latch2.Rearscreen

6.Thoroughlycleanthescreenwithcompressed

air.

7.Rotatethe2oil-coolerlatchesinward,andtilt

oilcooler(Figure95).
