g375763
Figure65
1.Frontofthemachine
3.Rear-axletube
2.Jackbrackets(front-axle
tube)
4.Backofthemachine
•Front—thejackbracketsofthefront-axletube
(Figure65).
•Rear—therear-axletube.
Lubrication
GreasingtheBearingsand
Bushings
ServiceInterval:Every50hours(andimmediately
aftereverywashing).
GreaseSpecication:No.2lithiumgrease
1.Preparethemachineformaintenance;referto
PreparingforMaintenance(page40).
2.Openthehood;refertoOpeningtheHood(page
40).
3.Thelubricatethemachineatthettingsatthe
locationsasfollows:
•Pump-driveshaftU-joint(3)(Figure66)
Note:Thepump-driveshaftislocatedUnder
thehood.
g003962
Figure66
•Cutting-unitlift-armcylinders(2each)
(Figure67)
g012150
Figure67
42
