1.Removethe3bolts,washers,andspacerssecuringthetractionmanifoldtothebottomoftherear

bumper(Figure33a).

2.Positiontheappropriateamountofweightonthetopand/orbottomoftherearbumper.

3.Mounttheweight(s)andthetractionmanifoldtothebumperwiththe3bolts,washersandspacers

previouslyremoved(Figure33b).

Note:Donotusethespacerswheninstallingmorethantwoweightsunderthebumper(Figure33c).

4.Securetheouteredgesoftheweight(s)tothebumperwith2carriageboltsandnuts(Figure33c).

InstallingtheCEHoodLock

Partsneededforthisprocedure:

1Hoodlock,seal,andjamnut

1Washer

Procedure

1.Unlatchandraisethehood.

2.Removetherubbergrommetfromtheholein

theleftsideofthehood(Figure34).

g004143

Figure34

1.Rubbergrommet

3.Ensurethatthesealisassembledtothehood

lock(Figure35).

g375326

Figure35

1.Hoodlatch

3.Seal

2.Nut4.Washer

4.Removethenutfromthelock.

5.Outsidethehood,insertthehookendofthe

latchthroughtheholeinthehood.

Note:Thesealisalignedtotheoutsideofthe

hood.

6.Insidethehood,Securethelocktothehood

withthewasherandnut.

7.Closethehood,andusetheenclosedhood-latch

keytocheckthatthehookofthelockengages

theframecatchwhenlocked.
