CoolingSystem
Maintenance
CoolingSystemSafety
•Swallowingenginecoolantcancausepoisoning;
keepoutofreachfromchildrenandpets.
•Dischargeofhot,pressurizedcoolantortouching
ahotradiatorandsurroundingpartscancause
severeburns.
–Alwaysallowtheenginetocoolatleast15
minutesbeforeremovingtheradiatorcap.
–Usearagwhenopeningtheradiatorcap,and
openthecapslowlytoallowsteamtoescape.
CoolantSpecication
Thecoolantreservoirislledatthefactorywitha
50/50solutionofwaterandethyleneglycolbase
extended-lifecoolant.
Important:Useonlycommerciallyavailable
coolantsthatmeetthespecicationslistedinthe
ExtendedLifeCoolantStandardsTable.
Donotuseconventional(green)inorganic-acid
technology(IAT)coolantinyourmachine.Do
notmixconventionalcoolantwithextended-life
coolant.
CoolantTypeTable
Ethylene-GlycolCoolant
Type
CorrosionInhibitorType
Extended-lifeantifreezeOrganic-acidtechnology
(OAT)
Important:Donotrelyonthecolorofthecoolant
toidentifythedifferencebetweenconventional(green)
inorganic-acidtechnology(IAT)coolantandextended-life
coolant.
Coolantmanufacturersmaydyeextended-lifecoolantin
oneofthefollowingcolors:red,pink,orange,yellow,
blue,teal,violet,andgreen.Usecoolantthatmeetsthe
specicationsintheExtendedLifeCoolantStandards
Table.
ExtendedLifeCoolantStandards
ATSMInternationalSAEInternational
D3306andD4985J1034,J814,and1941
Important:Coolantconcentrationshouldbea
50/50mixtureofcoolanttowater.
•Preferred:Whenmixingcoolantfroma
concentrate,mixitwithdistilledwater.
•Preferredoption:Ifdistilledwaterisnotavailable,
useapre-mixcoolantinsteadofaconcentrate.
•Minimumrequirement:Ifdistilledwaterand
pre-mixcoolantarenotavailable,mixconcentrated
coolantwithcleandrinkablewater.
CheckingtheCoolantLevel
CAUTION
Iftheenginehasbeenrunning,the
pressurized,hotcoolantcanescapeand
causeburns.
•Donotopentheradiatorcapwhenthe
engineisrunning.
•Usearagwhenopeningtheradiatorcap,
andopenthecapslowlytoallowsteamto
escape.
CoolantCapacity:9.5L(10.0USqt)
1.Preparethemachineformaintenance;referto
PreparingforMaintenance(page40).
2.Openthehood;refertoOpeningtheHood(page
40).
3.Checkthelevelofcoolantinthereservoir
(Figure93).
Note:Thecoolantleveliscorrectifitiscold
markonthesideofthetankwhentheengineis
cold,andthehotmarkwhentheengineishot.
54
