InstallingRearWeights
Partsneededforthisprocedure:
Varies
Rearweights(sizevarieswithconguration)
Procedure
ThismachinecomplieswithENISO5395andANSIB71.4-2017whenequippedwithrearweightsand/or
41kg(90lb)ofcalciumchlorideballastisaddedtorearwheels.Usethefollowingchartstodeterminethe
combinationsofweightsrequiredforyourconguration.OrderpartsfromyourlocalauthorizedT orodistributor.
WeightP/N110-8985-03
Groomers,roller
brushes,and/or
baskets
Numberofweights
tomeetANSI(US)
standards
Numberofweightsto
meetCE(European)
standards
Fasteners(2each
required)forweights
WeightLocation
No00
N/AN/A
Yes44
3231-7CarriageBolt,
104-8301Nut
1ontopofbumperand
3underbumper
Important:Alwaysinstalltubesinsidethereartiresbeforecalciumchlorideisinstalled.Ifapuncture
occursinatirewithcalciumchloride,removethemachinefromtheturfareaasquicklyaspossible.To
preventpossibledamagetotheturf,immediatelysoaktheaffectedareawithwater.
Usethefollowingproceduretomounttheappropriateamountofweight(seeweightcharts)tothetopor
bottomoftherearbumperasshowninFigure33.
g005526
Figure33
1.Tractionmanifold5.Weight(s)
2.Spacers6.Carriagebolt
3.Bolts7.Nut
4.Washers
