Donotpushortowthemachineformorethan1/4
mile(0.4km).
Important:Donotpushortowthemachine
fasterthan2-3MPH(3-4.8km/h)becauseinternal
transmissiondamagemayoccur.Thebypassvalve
mustbeopenwheneverthemachineispushedor
towed.
1.Raisetheseatandremovethebatterycover.The
bypassvalveislocatedinfrontofthebattery
(Figure28).
2.Rotatethevalve1/4turnineitherdirectiontoopen
andallowoiltobypassinternally.Becauseuidis
bypassed,themachinecanbeslowlymovedwithout
damagingthetransmission.Notethepositionof
thevalvewhenopeningorclosing.
3.Closethebypassvalvebeforestartingtheengine.
However,donotexceed5to8ft-lb(7to11N⋅m)
torquetoclosethevalve.
Figure28
1.Bypassvalveaccesshole
Important:Ifthemachinemusttobe
pushedortowedinreverse,thecheckvalve
inthefour-wheeldrivemanifoldmustalsobe
bypassed.Tobypassthecheckvalve,connect
ahoseassembly(HosePartNo.95-8843,
CouplerFittingNo.95-0985[Qty.2],and
HydraulicFittingNo.340-77[Qty.2])tothe
reversetractionpressuretestport(Figure29)
andthereversefour-wheeldrivepressureport
(Figure30).
Figure29
1.Reversetractionpressuretestport
Figure30
1.Reversefour-wheeldrivepressuretestport
JackingPoints
Therearejackingpointslocatedatthefrontandrear
ofthemachine.
•Ontheframeattheinsideofeachfrontdrivetire
•Atthecenteroftherearaxle
TieDowns
Therearetiedownslocatedatthefront,rearandsides
ofthemachine.
•Oneachsideoftheframebythesidecuttingunit
liftarms
•Frontcenteroftheoperator’splatform
•Therearbumper
OperatingCharacteristics
Practicedrivingthemachinebecauseithasahydrostatic
transmissionanditscharacteristicsaredifferentthan
manyturfmaintenancemachines.Somepointsto
considerwhenoperatingthetractionunit,cutting
unit,orotherimplementsarethetransmission,engine
29
