Figure74

1.Adjustmentscrew2.Decklatch

Pivoting(Tilting)theFront

CuttingUnitUpright

Note:Althoughnotneededfornormalmaintenance

procedures,thefrontcuttingunitcanbepivoted(tilted)

toanuprightposition(Figure75).Shouldyoudesireto

tiltthecuttingunit,proceedasfollows:

Figure75

1.Raisethefrontcuttingunitslightlyoffoftheoor,

settheparkingbrake,andstoptheengine.Remove

theignitionkey.

2.Removethehairpincotterandclevispinsecuringthe

decktransportlatchtothelatchplate(Figure76).

Pivotlatchtowardrearofdeck.

Figure76

1.Transportlatch2.Latchplate

3.Removethehairpincotterandclevispinsecuringthe

height-of-cutchainstotherearofthecuttingunit.

4.Starttheengine,slowlyraisethefrontcuttingunit,

andstoptheengine.Removetheignitionkey.

5.Graspthefrontofthecuttingunitandliftittoan

uprightposition.

6.Holdthecuttingunitupright,tthecableendover

thepinonthecuttingunitliftarmandsecureitwith

thehairpincotter(Figure77).

Figure77

1.Cable

2.Pin

PivotingtheFrontCuttingUnit

Down

1.Withthehelpofanotherperson,holdthecutting

unitupright,removethehairpincottersecuringthe

cableend,andremovethecablefromthepin.

2.Pivot(tilt)thecuttingunitdownward.

3.Storethecableundertheoperator’splatform.

4.Sitontheseat,starttheengine,andlowerthecutting

unituntilitisslightlyoffoftheoor.
