CheckingtheRearWheel
Toe-In
ServiceInterval:Every800hours
Afterevery800operatinghoursorannually,checkthe
rearwheeltoe-in.
1.Measurethecenter-to-centerdistance(ataxleheight)
atthefrontandrearofthesteeringtires.Thefront
measurementmustbe1/4inch(6mm)lessthanthe
rearmeasurement.
2.Toadjust,loosentheclampsatbothendsofthetie
rods.
3.Rotatethetierodendtomovethefrontofthetire
inwardoroutward.
4.Tightenthetierodclampswhentheadjustmentis
correct.
CoolingSystem
Maintenance
ServicingtheEngineCooling
System
ServiceInterval:Every100hours
Every2years
Thismachineisequippedwithahydraulicallydrivenfan
drivesystemthatautomatically(ormanually)reverses
toreduceradiatorandscreendebrisbuild-up.While
thisfeaturecanhelpreducethetimerequiredtoclean
radiatorsandcoolers,itdoesnoteliminatetheneedfor
routinecleaning.Periodiccleaningandinspectionof
theradiatorisstillrequired.
Removedebrisfromtheoilcoolerandradiator
daily.Cleanthemmorefrequentlyindirtyconditions.
1.Turntheengineoffandraisethehood.Cleanthe
engineareathoroughlyofalldebris.
2.Removetheknobs(Figure61)securingtheoilcooler
totheframe.
Figure61
1.Knobs
3.Pivottheoilcoolerrearward.Cleanbothsidesofthe
oilcoolerandradiatorarea(Figure62)thoroughly
withcompressedair.Startfromthefansideand
blowthedebrisouttowardstheback.Thenclean
fromthebacksideandblowtowardsthefront.
Repeatprocedureseveraltimesuntilallchaffand
debrisisremoved.
Important:Cleaningtheradiatororoilcooler
withwatercanpromoteprematurecorrosion
anddamagetocomponents.
