Ifyouleavethekeyintheignitionswitch,someonecouldaccidentlystarttheengineandseriously
injureyouorotherbystanders.
Removethekeyfromtheignitionbeforeyoudoanymaintenance.
ServiceIntervalChart
Figure32
Lubrication
GreasingtheBearingsand
Bushings
Themachinehasgreasettingsthatmustbelubricated
regularlywithNo.2GeneralPurposeLithiumBase
Grease.Ifthemachineisoperatedundernormal
conditions,lubricateallbearingsandbushingsafter
every50hoursofoperationorimmediatelyafterevery
washing.
Thegreasettinglocationsandquantitiesare:
TractionUnit
ServiceInterval:Every50hours
•Brakeshaftpivotbearings(5)(Figure33)
•Tractionpedalpivotbushing(1)(Figure34)
•Frontandrearaxlepivotbushings(2)(Figure35)
•Steeringcylinderballjoints(2)(Figure36)
•Tierodballjoints(2)(Figure36)
•Kingpinbushings(2)(Figure36).
Thetopttingonthekingpinshould
onlybelubricatedannually(2pumps).
