Toro Lynx User Manual

29
DT35 Mainless Nozzle Performance Data—(U.S.)
Green Plug Grey
102-6531 102-2208 102-2910
Green Plug Green
102-6531 102-2208 102-6885
Green Plug Red
102-6531 102-2208 102-2928
Green Plug Beige
102-6531 102-2208 102-2929
PSI Radius GPM Radius GPM Radius GPM Radius GPM
65 34 10.4 44 10.2 48 11.5 50 13.5
SOR 3:40 3:50 3:25 2:40
80 37 11.6 44 11.4 48 12.9 50 15.0
SOR 3:15 3:25 3:00 2:30
Mainless and Back Nozzle Data
835S Series Mainless Nozzle Performance Data—(Metric)
Blue - Plug - Gray
102-2925 102-2208 102-2910
Orange - Plug - Gray
102-2926 - 102-2208 - 102-2910
Red - Plug - Gray
102-2928 - 102-2208 - 102-2910
Gray - Plug - Gray
102-2910 - 102-2208 - 102-2910
Gray - Plug - Gray
102-2930 - 102-2208 - 102-2910
Bar kPa kg/cm2 Radius LPM Radius LPM Radius LPM Radius LPM Radius LPM
4,5 448 4,6 14,0 32,9 14,0 39,4 15,2 46,9 12,8 38,6 14,3 52,6
SOR 5:02 4:16 3:36 4:19 4:06
80 46 9,6
14,0 36,3 14,3 43,5 16,2 51,9 13,4 42,4 15,5 57,9
SOR 4:22 3:40 3:03 3:53 3:40
Back Nozzle Performance Data—(U.S.)
Nozzles 65 PSI 80 PSI
Part # Description Color Radius GPM Radius GPM Profile
102-6937 Inner Nozzle w/ Yellow Restrictor Yellow/Yellow 29 3.7 30 4.1
102-6531 Inner Nozzle w/ White Restrictor Green/White 31 4.3 33 4.6
102-6883 Intermediate Nozzle Brown 38 2.8 38 2.8
102-6884 Intermediate Nozzle Yellow 41 4.1 43 4.5
102-6885 Intermediate Nozzle Green 42 5.4 45 6.0
102-2925 Intermediate Nozzle Blue 40 2.8 42 3.2
102-2926 Intermediate Nozzle Orange 44 4.3 45 4.8
102-2927 Intermediate Nozzle Gray 46 5.1 47 5.4
102-2928 Intermediate Nozzle Red 48 6.5 50 7.0
102-2929 Intermediate Nozzle Beige 51 8.1 53 9.1
Back Nozzle Performance Data—(Metric)
Nozzles
4,5 Bar 448 kPa 4,6 kg/cm2 5,5 Bar 552 kPa 5,6 kg/cm2
Part # Description Color Radius -m LPM Radius - m LPM Profile
102-6937 Inner Nozzle with Yellow Restrictor Yellow/Yellow 8,8 14,0 9,2 15,5
102-6531 Inner Nozzle with White Restrictor Green/White 9,5 16,3 10,1 17,4
102-2135 Inner Nozzle with White Restrictor White/White 7,6 15,5 7,9 17,0
102-2136 Inner nozzle assy w/ yel restrictor Yellow/Yellow 7,3 14,4 7,6 15,5
102-6883 Intermediate Nozzle Brown 11,6 10,6 11,6 10,6
102-6884 Intermediate Nozzle Yellow 12,5 15,5 13,1 17,0
102-6885 Intermediate Nozzle Green 12,8 20,4 13,7 22,7
102-2925 Intermediate Nozzle Blue 12,2 10,6 12,8 12,1
102-2926 Intermediate Nozzle Orange 13,4 16,3 13,7 18,2
102-2927 Intermediate Nozzle Gray 14,0 19,3 14,3 20,4
102-2928 Intermediate Nozzle Red 14,6 24,6 15,3 26,5
102-2929 Intermediate Nozzle Beige 15,6 30,7 16,2 34,4
DT35 Mainless Nozzle Performance Data - (Metric)
Green Plug Grey
102-6531 102-2208 102-2927
Green Plug Green
102-6531 102-2208 102-6885
Green Plug Red
102-6531 102-2208 102-2928
Green Plug Beige
102-6531 102-2208 102-2929
Bar kPa kg/cm2 Radius LPM Radius LPM Radius LPM Radius LPM
4,5 448 4,6 10,4 39,4 13,4 38,6 14,6 43,5 15,3 51,1
SOR 3:40 3:50 3:25 2:40
80 46 9,6
11,3 43,9 13,4 43,1 14,6 48,8 15,3 56,8
SOR 3:15 3:25 3:00 2:30
835S Series Mainless Nozzle Performance Data—(U.S.)
Blue - Plug - Gray
102-2925 102-2208 102-2910
Orange - Plug - Gray
102-2926 - 102-2208 - 102-2910
Red - Plug - Gray
102-2928 - 102-2208 - 102-2910
Gray - Plug - Gray
102-2910 - 102-2208 - 102-2910
Gray - Plug - Gray
102-2930 - 102-2208 - 102-2910
PSI Radius GPM Radius GPM Radius GPM Radius GPM Radius GPM
65 46 8.7 46 10.4 50 12.4 42 10.2 47 13.9
SOR 5:02 4:16 3:36 4:19 4:06
80 46 9.6 47 11.5 53 13.7 44 11.2 51 15.3
SOR 4:22 3:40 3:03 3:53 3:40
