Specifying Information—DL2000
®
Model Number Description
SSDS-LF-500
SSDS-HF-1000
RGP-212-05
DL2000 500' Subsurface Drip System—Low Flow
DL2000 1000' Subsurface Drip System—High Flow
DL2000 500’ (Roll, 0.5 GPH), 12” Spacing
DL2000
®
Subsurface
Drip Irrigation System
Features
• Pressure compensating emitters
• Each emitter is impregnated with Treflan, a root inhibitor
that prevents roots from entering and clogging the emitter
opening
• The airjection system draws a measured amount of air into
the system to deliver oxygen rich water directly to the root
zone to promote healthy plant growth
• The air relief valve opens at the end of every watering cycle
allowing clean air to enter the system and eliminate emitter
clogging from siphoning
• Applies water directly to the root zone allowing turf to stay
dry
• Uniformly applies water to areas such as fingers
• Minimizes runoff
• Eliminates overspray into bunker keeping sand dry
• Cycle/soak allows for application on steep slopes
• Reduces bunker cave-ins
• Saves time, labor and money by eliminating the need for
hand-watering
Drip System Specifications
• Flow range:
• Low flow: 0,4 to 30,3 LPM (0.1 to 8.0 GPM)
• High flow: 7,6 to 75,7 LPM (2.0 to 20.0 GPM)
• DL2000 range:
• Low flow: 3,7m to 304,8m (12’ to 1000’)
• High flow: 76,2m to 762m (250’ to 2500’)
• Pressure compensating emitter: 1,9 LPH (0.5 GPH)
• DL2000 Maximum run length: 76,2m (250’)
• Application rate 30,48cm (12” x 12”) spacing:
21 mm/h (0.85”/h)
System Components
• DL2000 subsurface dripline
• Low Flow system – 152,4m (500’)
• High Flow system – 304,8m (1000’)
• Drip Zone Valve Kit – includes control valve, pressure
regulator, Y-filter and manual ball valve
• Air Vent Assembly – pre-assembled and ready to install for
labor savings
• Required inlet/outlet fittings
• Flush Assembly Fittings 8 GPM (2 psi) sealing flush valve
• Installation Fittings:
• Includes Toro exclusive Loc-Eze® tees, couplings, elbows
and end clamps
• 3,1m (10’) of Blue Stripe® polyethylene tubing
• Soil staples for secure tubing placement
• Pipe thread tape
Warranty
• 2 Years
