Key/IgnitionSwitchTesting(continued)
g331211
Figure86
5.Usingadigitalmulti-metersettotheOHMorContinuitysetting,verifythat
NOcontinuityexistsbetweentheterminalsnotlistedforeachswitchposition.
Position
Circuit“Make”
1.OFF
None
RunB+R+I+A
3.StartB+R+I+S
Hourmeter
ThehourmeterrecordshoursofoperationwhentheignitionkeyisONandthe
PTOswitchisON.
g322162
Figure87
HourmeterTesting
1.Withoutstartingtheengine,withtheignitionswitchinthe“RUN”position
andthePTOswitchclosed(ON)verifythebatteryvoltageandgroundto
thehourmeter.
TitanServiceManual
Page8–5
Electrical:ServiceandRepairs
3438-774RevA
