MotionControlAssemblyReplacement

MotionControlAssemblyRemoval

g321537

Figure52

1.Bolt

3.MotionControlDamper

2.MotionControlLinkage

1.ParkthemachineonalevelsurfaceanddisengagethePTO.Stopthe

engine,waitforallmovingpartstostop,andremovekey.

2.Disconnectthebatterybyremovingthenegativecablerst,thenthepositive

cablefromthebattery.

3.Raiseandsupporttheunitsothatthedrivewheelsareofftheground.

Note:Theconsolemustberemovedforaccess.

4.Removethe2boltssecuringthemotioncontrolhandletothemotioncontrol

assembly.

5.Disconnectthemotioncontroldamperfromthemotioncontrolassembly.

6.Disconnectthemotioncontrollinkagefromthemotioncontrolassembly.

7.Disconnectthemotioncontrolassemblyfromtheframe.

Chassis:ServiceandRepairs

Page5–26

TitanServiceManual

3438-774RevA
