MowerBeltInstallation(continued)
4.Installthebeltcovers.Torquethebeltcoverboltsto6–8N•m(50–75in-lb).
5.Tightentheboltstosecurethecovertothedeck.
6.Connectthebatterybyinstallingthepositivecablerst,thenthenegative
cabletothebattery.
MowerDeckReplacement
MowerDeckRemoval
1.ParkthemachineonalevelsurfaceanddisengagethePTO.Stoptheengine,
waitforallmovingpartstostop,andremovekey.Engagetheparkingbrake.
2.Disconnectthebatterybyremovingthenegativecablerst,thenthepositive
cablefromthebattery.
3.Removetheheightadjustmentpinandlowerthedecktotheground.
4.Removethemowerbelt.
5.Removethe2hairpinsandwashersthatsecurethelinkpintotheframe
anddeck,thenremovethelinkpin.
g322064
Figure78
1.LinkPin3.Washer
2.HairpinCotter
6.Liftthemowerdecktoremovetensionfromthechainsandunhookthe
chainsfromthedeckliftarms.
7.Raisetheheight-of-cuttothetransportposition.
8.Slidethedeckoutfromunderneaththemachine.
MowerDeckInstallation
1.Placethedeckonthegroundandslideitintopositionunderneaththe
machine.
2.Lowertheheight-of-cutintothelowestpositionandsecurewiththe
height-of-cutpin.
3.Lifttherearofthemowerdeckandattachthechainstotherearliftarms.
4.Attachthefrontchainstothefrontdeckliftarms.
TitanServiceManual
Page7–7
MowerDeck:ServiceandRepairs
3438-774RevA
