CasterWheelBearingInstallation

1.Installnewbearings(bearingsmayhaveaslightpresst).

Note:Thebearingsaresealedanddonotrequiregrease/lubrication.They

mayalsohaveaslightpresst.

2.Installthespannerintothecasterwheel,theninstallfeltwashersanddust

capsoverthecasterbearings.

3.Placethecasterwheelinsideofthecasterfork,aligningthespannerwith

theholesinthecasterfork.

4.Installtheboltandnutandtorqueto44±7N•m(32±5ft-lb).

5.Lowertheunitandverifyproperfunction.

6.Installnewbearings(bearingsmayhaveaslightpresst).

7.Connectthebatterybyinstallingthepositivecablerst,thenthenegative

cabletothebattery.

LeftConsoleReplacement

LeftConsoleRemoval

1.ParkthemachineonalevelsurfaceanddisengagethePTO.Stoptheengine,

waitforallmovingpartstostop,andremovekey.Engagetheparkingbrake.

2.Disconnectthebatterybyremovingthenegativecablerst,thenthepositive

cablefromthebattery.

3.Removethe3(T30)shoulderscrewsfromtheleftconsole.

g321205

Figure19

4.Removethefuelcapanddisconnectthekeeperline.

Chassis:ServiceandRepairs

Page5–6

TitanServiceManual

3438-774RevA
