MowerDeckInstallation(continued)

5.Installthelinkpinthroughtheframehangerandthedeck.Securewith

hairpinsandwashersthatwerepreviouslyremoved.

6.Installthemowerbeltontotheenginepulleyrst,thenontothemowerdeck.

7.Installthemowerbeltcovers.T orquethebeltcoverboltsto6–8N•m(50–75

in-lbs).

8.Raisethedecktothe76mm(3inches)height-of-cutpositionandcheck

fordecklevel.

9.Connectthebatterybyinstallingthepositivecablerst,thenthenegative

cabletothebattery.

MowerSpindle

MowerSpindleRemoval

1.ParkthemachineonalevelsurfaceanddisengagethePTO.Stoptheengine,

waitforallmovingpartstostop,andremovekey.Engagetheparkingbrake.

2.Disconnectthebatterybyremovingthenegativecablerst,thenthepositive

cablefromthebattery.

3.Removethemowerbeltcovers.

4.Removethemowerbelt.

5.Removethecuttingblade.

6.Removethe6selftappingboltsthatsecurethespindletothedeck.

7.Pullthespindleassemblydownward,throughthedeck.

MowerSpindleInstallation

1.Positionthespindleagainstthedeckandalignthemountingholes.

Note:Ensuretheundersideofthedeckiscleanbeforeproceedingwith

thespindleinstallation.

2.Install6taptitescrews.

Note:Spindletaptitescrewsarethreadforming.Donotreusespindle

mountingscrews.

3.Installthebellevillewasherwiththeconcavesidefacingthecuttingblade;

installthebladebolt.Torquethebladeboltto138–152N•m(100-110ft-lb).

4.Installthemowerbelt.

5.Installthemowerbeltcovers.

6.Connectthebatterybyinstallingthepositivecablerst,thenthenegative

cabletothebattery.

MowerDeck:ServiceandRepairs

Page7–8

TitanServiceManual

3438-774RevA
