Toshiba 40L310U User Manual

15
40L310U Toshiba 40" 1080p 60Hz LED TV
U.S.: http://support.toshiba.com Canada: http://support.toshiba.ca/support/ceg/
DVI (same as HDMI but requires an audio connection)
1 Make sure that your TV’s power cord is unplugged and all connected equipment is turned off.
2 Connect the incoming cable from the cable wall jack to the cable-in jack on the cable or satellite box.
3 Connect an HDMI-DVI adapter (not provided) to one end of an HDMI cable (not provided), then connect the adapter
to the DVI OUT jack on the cable or satellite box.
4 Connect the other end of the cable to the HDMI IN 1 (DVI) jack on the back of your TV.
5 Plug your TV’s power cord into a power outlet, turn on your TV, then turn on the cable or satellite box.
6 Press INPUT to open the Input Selection list.
7 Press
S or T to highlight HDMI 1, then press ENTER.
Notes
• You must use the HDMI IN 1 (DVI) jack to connect a cable box using
DVI.
• Your TV supports DVI video only. To add sound for a DVI connection,
connect external speakers or a sound bar to the cable or satellite box.
Cable or
satellite box
HDMI cable with HDMI-DVI adapter
Back of TV
HDMI cable
connector
HDMI IN 1
(DVI) jack
On your TV
Cable
wall jack

Toshiba 40L310U Specifications

General

Screen Type	led
Wall Mount	200mm x 200mm
Screen Size	39.5 inches, 40 inches
Refresh Rate	60hz
Brightness	250 candela per square meter
Surround Sound	dts trusurround
Speakers Output	14 watts
Number Of Speakers	2
USB Ports	1
RF Antenna	yes
Network	none
Headphones Output	no
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
3D	no
Power Consumption	108 kilowatt hours
Depth with Stand	7.5 inches
Height with Stand	22.3 inches
Width with Stand	35.6 inches
Net Weight with Stand	21.8 pounds
Depth without Stand	2.7 inches
Height without Stand	20.2 inches
Net Weight without Stand	21.4 pounds
