Air outlet/Air outlet flap
Exchanges the air direction according to
cooling or heating time.
Earth screw
It is prepared in the electric parts box.
Air inlet port
Sucks air inside of the room from here.
Air filter
Removes dirt or dust.
(It is included in the suction port.)
Air outlet port
Drain pan (With drain filter)
This accessory is installed at the local site.
Air filter
Removes dirt or dust.
(It is included in the suction port.)
Air inlet port
Sucks air inside of the room from here.
Earth screw
It is prepared in the electric parts box.
Earth screw
It is prepared in the electric parts box.
Front panel (Lower side)
Fixing metal holder
Vertical flap
The air can be automatically discharged
rightward/leftward at stated periods.
Horizontal flap/Air outlet port
Exchanges the air direction according
to cooling or heating time.
Air filter
Removes dirt or dust.
Air inlet port
Sucks air inside of the room from here.
Fixing metal holder (Right and left)
Drain pan
Water accumulated in the drain pan is
drained from here through the drain pipe.
[Under Ceiling Type]
[High Wall Type]
MMK-AP0071H to AP0241H
MMK-AP0072H to AP0122H
Air inlet grille
Air in the room is sucked from here.
Earth screw
Earth screws are provided in the electric
parts box.
Air filter
Removes dust and trash.
(Air filter is provided in the air inlet grille.)
Air outlet/Air outlet flap
Change the direction of the air to be
discharged according to cool/heat mode.
Button
Button to open/close the suction port
Air filter
Removes dust or trash.
(Provided on the suction port.)
Air inlet port
The air in the room is sucked in from this
port.
Earth screw
Earth screws are provided in the electric
parts box.
Air outlet/Air outlet flap
Change the direction of the air to be discharged according to cool/heat mode.
Air inlet grille
Air in the room is sucked from here.
Earth screw
Earth screws are provided in the electric
parts box.
Air outlet/Air outlet flap
Change the direction of the air to be
discharged according to cool/heat mode.
Air filter
Removes dust and trash.
(Air filter is provided in the air inlet grille.)
[Floor Standing Type]
[Floor Standing Concealed Type]
[Floor Standing Cabinet Type]
To Next Page
