Toshiba TOSVERT VF-AS3 User Manual

E6582062
1. Read first 1-4
1
9
This inverter has multi-rating.
Select rating with the parameter <AUL: Multi-rating select> according to the characteristics of the load to
be applied.
<AUL>="2: ND rating (120%-60s) (0 after execution)"
- Select it to apply equipment with variable torque characteristic.
- Example) Fans, pumps, blowers, etc.
<AUL>="3: HD rating (150%-60s) (0 after execution)"
- Select it to apply equipment with constant torque characteristic.
- Example) Conveyors, load transporting machinery, cranes, mixers, compressors, making machines,
machine tools, etc.
Both of them return to "0" after setting.
For details, refer to [5. 3. 2].
This instruction manual describes the motor capacity based on HD rating. In the case of ND rating, it is
described with parentheses like (ND: **kW).
1. 2 Multi-rating
