11.6 Input Terminal Function
Table of input terminal functions 1
Function
No.
Code Function Action Reference
0,1 - No function Disabled -
2 F Forward run command ON: Forward run, OFF: Slowdown stop 3.2.1
3 FN Inversion of forward run command Inversion of F 7.2.1
4 R Reverse run command ON: Reverse run, OFF: Slowdown stop 3.2.1
5 RN Inversion of reverse run command Inversion of R 7.2.1
6 ST Standby ON: Ready for operation
OFF: Coast stop (gate OFF)
3.2.1
7 STN Inversion of standby Inversion of ST
8 RES Reset command ON: Acceptance of reset command
ON OFF: Trip reset
13.2
9 RESN Inversion of reset command Inversion of RES
10 SS1 Preset-speed command 1
Selection of 15-speed SS1 to SS4 (SS1N to SS4N) (4 bits)
3.6
11 SS1N Inversion of preset-speed command 1 7.2.1
12 SS2 Preset-speed command 2
13 SS2N Inversion of preset-speed command 2
14 SS3 Preset-speed command 3
15 SS3N Inversion of preset-speed command 3
16 SS4 Preset-speed command 4 3.6
17 SS4N Inversion of preset-speed command 4
18 JOG Jog run mode ON: Jogging mode (fixed at 5Hz)
OFF: Jog run canceled
7.2.1
19 JOGN Inversion of jog run mode Inversion of JOG
20 EXT Emergency stop by external signal ON: trip stop
OFF: After stopped by f603, e trip
6.16.4
21 EXTN Inversion of emergency stop by external signal Inversion of EXT
22 DB DC braking command ON: DC braking, OFF: Brake canceled 6.7.1
23 DBN Inversion of DC braking command Inversion of DB
24 AD2 2nd acceleration/deceleration ON: Acceleration/deceleration 2
OFF: Acceleration/deceleration 1
6.4.1
6.15.1
25 AD2N Inversion of 2nd acceleration/deceleration Inversion of AD2
28 VF2 2nd V/F control mode switching ON: 2nd V/F control mode
(V/F fixed, , , , )
OFF: 1st V/F control mode
( setting, , , , )
6.4.1
29 VF2N Inversion of 2nd V/F control switching Inversion of VF2
32 OCS2 2nd stall prevention level ON: Enabled at the value of
OFF: Enabled at the value of
6.4.1
6.16.2
33 OCS2N Inversion of 2nd stall prevention level Inversion of OCS2
36 PID PID control prohibition ON: PID control prohibited
OFF: PID control enabled
6.13
37 PIDN Inversion of PID control prohibition Inversion of PID
48 SCLC Forced local from communication Enabled during communication
ON: Local (Setting of , )
OFF: Communication
5.5
6.19
49 SCLCN Inversion of forced local from communication Inversion of SCLC
50 HD Operation hold (hold of 3-wire operation) ON: F (forward run), R: (reverse run) held, 3-wire operation
OFF: Slowdown stop
7.2.1
51 HDN Inversion of operation hold (hold of 3-wire
operation)
Inversion of HD
52 IDC PID integral/differential clear ON: Integral/differential clear, OFF: Clear canceled 6.13
53 IDCN Inversion of PID integral/differential clear Inversion of IDC
54 PIDSW PID characteristics switching ON: Inverted characteristics of selection
OFF: Characteristics of selection
55 PIDSWN Inversion of PID characteristics switching Inversion of PIDSW
