E6581595
E-1
5
5. Main parameters
Before you operate the inverter, the parameters that you must first program are the basic parameters.
Refer to section 11 tables of basic parameters.
5.1 Searching for changes using the history function
()
: History function
History function ():
Automatically searches for 5 latest parameters that are programmed with values different from the
standard default setting and displays them in the . Parameter setting can also be changed
within this group .
Notes on operation
If no history information is stored, this parameter is skipped and the next parameter “” is
displayed.
and are added respectively to the first and last parameters in a history of changes.
How to use the history function
Operation panel
action
LED display Operation
Displays the output frequency (operation stopped).
(When standard monitor display selection = [Output frequency])
The first basic parameter “” (history function) is displayed.
The parameter that was set or changed last is displayed.
Press the center of the setting dial to display the set value.
Turn the setting dial to change the set value.
Press the center of the setting dial to save the changed value. The
parameter name and the programmed value will flash on and off
alternately.
****
Turn the dial as described above to search for and display changed
parameters to check and change the settings.
()
: First historic record
: Last historic record
MODE
To Next Page
