E6581611
E-23
5
5.10 Changing operation panel display
5.10.1 Changing the unit (A/V) from a percentage of current
and voltage
f701 :Current/voltage unit selection
Function
These parameters are used to change the unit of monitor display.
% A (ampere)/V (volt)
Current 100% = Rated current of inverter
Voltage 100% = 200Vac (240V class), 400Vac (500V class)
Example of setting
During the operation of the VFS15-2015PM-W (rated current: 8.0A) at the rated load (100% load), units are
displayed as follows:
1) Display in percentage terms 2) Display in amperes/volts
[Parameter setting]
Title Function Adjustment range Default setting
f701
Current/voltage unit
selection
0: %
1: A (ampere) / V (volt)
0
* The f701 converts the following parameter settings:
A display : Current monitor display: Load current, torque current
Motor electronic-thermal protection level 1 & 2 , f173
DC braking current f251
Stall prevention level 1 & 2 f601, f185
Small current detection current f611
Brake releasing small current detection level f326
V display : Voltage monitor display: Input voltage, output voltage
V/f 5-point setting VF1-5 voltage f191, f193, f195, f197, f199
Note) Base frequency voltage 1 & 2(, ) always displayed in the unit of V.
Output current:
8. 0A
Input voltage:
20 0 V
Input voltage:
100%
Output current
100%
%
%
