E6581611
F-134
6
6.35 Tracing functions
f740 : Trace selection
f741 : Trace cycle
f742 : Trace data 1
f743 : Trace data 2
f744 : Trace data 3
f745 : Trace data 4
For details, refer to ”Trace Function Instruction Manual : E6581922”.
6.36 Integrating wattmeter
f748 : Integrating wattmeter retention selection
f749 : Integrating wattmeter display unit selection
Function
At the main power off, display unit of integral output power values and whether or not retain integral output
power values are selectable.
The integrating wattmeter display can be cleared by the signal to the input terminal.
Input terminal function 74, 75 (Integrating wattmeter display clear)
Title Function Adjustment range Default setting
f748 Integrating wattmeter retention selection
0: Disabled
1: Enabled
0
f749 Integrating wattmeter display unit selection
0:1=1kWh
1:1=10kWh
2:1=100kWh
3:1=1000kWh
4:1=10000kWh
Depends on
the capacity
(Refer to
section 11.4)
6.37 Parameter registration to easy setting mode
f750 : EASY key function selection
f751 to f782 : Easy setting mode parameter 1 to 32
Up to 32 arbitrary parameters can be registered to easy setting mode.
Refer to section 4.5 for details.
