12.2 Outside dimensions and mass
 Outside dimensions and mass
Voltage class
Applicable
motor (kW)
Inverter type
Dimensions (mm)
Drawing
Approx. weight
(kg)
W H DW1H1H2D2
3-phase 240V
0.4 VFS15-2004PM-W
72
130
120
60
121.5 13
7.5
A
0.9
0.75 VFS15-2007PM-W
130
1.0
1.5 VFS15-2015PM-W
105 93
B
1.4
2.2 VFS15-2022PM-W 1.4
4.0 VFS15-2037PM-W 140 170 150 126 157 14 C 2.2
5.5 VFS15-2055PM-W
150 220 170 130 210 12 D
3.5
7.5 VFS15-2075PM-W 3.6
11 VFS15-2110PM-W
180 310 190 160 295 20 E
6.8
15 VFS15-2150PM-W 6.9
1-phase 240V
0.2 VFS15S-2002PL-W
72
130
101
60
131
13
7.5
A
0.8
0.4 VFS15S-2004PL-W 120
121.5
1.0
0.75 VFS15S-2007PL-W 135 1.1
1.5 VFS15S-2015PL-W
105 150 93 12 B
1.6
2.2 VFS15S-2022PL-W 1.6
3-phase 500V
0.4 VFS15-4004PL-W
107 130 153 93 121.5 13
7.5
B
1.4
0.75 VFS15-4007PL-W 1.5
1.5 VFS15-4015PL-W 1.5
2.2 VFS15-4022PL-W
140 170 160 126 157 14 C
2.4
4.0 VFS15-4037PL-W 2.6
5.5 VFS15-4055PL-W
150 220 170 130 210 12 D
3.9
7.5 VFS15-4075PL-W 4.0
11 VFS15-4110PL-W
180 310 190 160 295 20 E
6.4
15 VFS15-4150PL-W 6.5
