Toyota 7FBEF 20 User Manual

10-7
mm (in)
Position
Vehicle model
7FBEF15 7FBEF16 7FBEF18 7FBEF20
A 1070 (42.1) 1070 (42.1) 1070 (42.1) 1125 (44.3)
B 900 (35.4) 900 (35.4) 900 (35.4) 990 (39.0)
C 915 (36.0) 915 (36.0) 915 (36.0) 915 (36.0)
D 180 (7.1) 180 (7.1) 180 (7.1) 225 (8.9)
E 80 (3.1) 80 (3.1) 80 (3.1) 100 (3.9)
F 1670 (65.7) 1720 (67.7) 1730 (68.1) 1825 (71.9)
G 1540 (60.1) 1640 (64.6) 1645 (64.8) 1710 (67.3)
H 175 (6.9) 175 (6.9) 175 (6.9) 205 (8.1)
I 3920 (154.3) 3920 (154.3) 3920 (154.3) 3920 (154.3)
J 3000 (118) 3000 (118) 3000 (118) 3000 (118)
K 1970 (77.6) 1970 (77.6) 1970 (77.6) 1970 (77.6)
L 150 (5.9) 150 (5.9) 150 (5.9) 125 (4.9)
M 40 (1.6) 40 (1.6) 40 (1.6) 40 (1.6)
N 800 (31.5) 800 (31.5) 800 (31.5) 1000 (39.4)
O 1895 (74.6) 1995 (78.5) 2000 (78.7) 2080 (81.9)
P 355 (14.0) 355 (14.0) 355 (14.0) 370 (14.6)
Q 1400 (55.1) 1505 (59.3) 1505 (59.3) 1505 (59.3)
R 1980 (78) 1980 (78) 1980 (78) 1980 (78)
S5° 5° 5° 5°
T6.5° 6.5° 6.5° 6.5°
