5-20
*1: Only on the vehicle with the mini lever (OPT).
H6-1 *1 H6-1 Tilt a2 (FRONT) solenoid abnormality (1) Tilt operation stop
C/R
H6-2 *1 H6-2 Tilt a2 (FRONT) solenoid abnormality (2)
Material handling dis-
abled
H6-3 *1 H6-3 Tilt b2 (REAR) solenoid abnormality (1) Tilt operation stop
H6-4 *1 H6-4 Tilt b2 (REAR) solenoid abnormality (2)
Material handling dis-
abled
H6-5 *1 H6-5 Tilt solenoid drive circuit abnormality
Material handling dis-
abled
H7-1 *1 H7-1 Attachment 1 a3 solenoid abnormality (1)
Attachment 1 operation
stop
C/R
H7-2 *1 H7-2 Attachment 1 a3 solenoid abnormality (2)
Material handling dis-
abled
H7-3 *1 H7-3 Attachment 1 b3 solenoid abnormality (1)
Attachment 1 operation
stop
H7-4 *1 H7-4 Attachment 1 b3 solenoid abnormality (2)
Material handling dis-
abled
H7-5 *1 H7-5
Attachment 1 solenoid drive circuit abnor-
mality
Material handling dis-
abled
H8-1 *1 H8-1 Attachment 2 a4 solenoid abnormality (1)
Attachment 2 operation
stop
C/R
H8-2 *1 H8-2 Attachment 2 a4 solenoid abnormality (2)
Material handling dis-
abled
H8-3 *1 H8-3 Attachment 2 b4 solenoid abnormality (1)
Attachment 2 operation
stop
H8-4 *1 H8-4 Attachment 2 b4 solenoid abnormality (2)
Material handling dis-
abled
H8-5 *1 H8-5
Attachment 2 solenoid drive circuit abnor-
mality
Material handling dis-
abled
H9-1 *1 H9-1 Unload valve solenoid open
Material handling dis-
abled
C/R
H9-2 *1 H9-2 Unload valve solenoid short
H9-3 *1 H9-3
Unload valve solenoid drive circuit abnor-
mality
Displayed
code
Diag
memory
code
Faulty Phenomenon on vehicle
Detection
controller
To Next Page
