1 -23
THREE THREAD OVEREDGING STITCH USING ONE NEEDLE
5. THREE THREAD OVEREDGING STITCH USING ONE
NEEDLE
Before removing the needle, switch the machine off.
Not doing so could cause an injury.
Though this machine is used mainly for 4 thread
overedging using 2 needles, three-thread
overedging using 1 needle can be easily operated
by just removing 1 needle.
(1) By removing the right needle
When using only the left needle and the left
thread tension (Dial Y), a wide stitch (normally
4.5mm) can be achieved.
倩 The differential feed ratio is normally "N".
(See P.19)
(2) By removing the left needle
When using only the right needle and the right
thread tension (Dial G), a narrow stitch (normally
2.5mm) can be achieved.
倩 The differential feed ratio is normally "N".
(See P.19)
Left needle
Right needle
To Next Page
