SPECIFICATIONS
12. SPECIFICATIONS
Number of threads 4 Threads (3 threads)
Number of needles 2 Needles (1 needle)
Needles
Standard
HA x 1T (705/130) #11(80)
#14(90)
or
HA x 1SP
Width between two needles 2 mm
Bite width Standard 4.5 mm
Size of bight (Range 4.2 到 6 mm)
Stitch length 1 到 4.4 mm
Differential feed ratio
1:0.7 到 2
Standard N (Neutral position)
Maximum sewing speed 1200 Stitches/min
Machine dimensions
Width 320 mm
Depth 250 mm
Height 340 mm (Max. 550 mm)
Weight (Head only) 7.5 kg
