TP-Link TL-R470T+ User Manual

-87-
Enable Logs:
Specify whether to log the E-Bulletin.
 E-Bulletin
Title:
Enter a title for the bulletin.
Content:
Enter the content of the bulletin.
Object:
Select the object of this bulletin. Options include:
 ANY: The bulletin will be released to all the users and the PCs on the
LAN.
 Group: The bulletin will be released to the users in the selected group.
You can click < > button to add a group to the selected group
and click <
> to remove a group from the selected group.
Group is created on User Group→Group page.
Effective Time:
Specify the effective time for the bulletin. Only one bulletin can be set for
the object at the same time.
Publisher:
Enter the name of the bulletin's publisher.
Description:
Enter the description for the bulletin.
Status:
Activate or inactivate the entry.
 List of E-Bulletin
In this table, you can view the existing bulletins and edit them by the Action button.
The No.1 entry in Figure 4-50 indicates: this bulletin is released by th
e administrator, and it is
released to the Group1 from 8am to 20pm on Thursday and Friday every a bulletin interval. (the
interval in the figure is 30 min). This entry is enabled.
Tips:
For the configuration for groups and users, please refer to the User Group section.
4.7.3 Dynamic DNS
DDNS (Dynamic DNS) service allows you to assign a fixed domain name to a dynamic WAN IP
address, which enables the Internet hosts to access the router or the hosts in LAN using the domain
names.

TP-Link TL-R470T+ Specifications

General

Full duplex	No
Static route	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Concurrent connections	10000
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet interface type	Fast Ethernet
Supported network protocols	TCP/IP, DHCP, ICMP, NAT, PPPoE, SNTP, HTTP, DNS
Ethernet LAN (RJ-45) ports	5
VPN support	PPTP/L2TP/IP Sec
Security algorithms	HTTPS
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Power consumption (typical)	1.56 W
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Flash memory	4 MB
Certification	CE, FCC, RoHS
Internal memory	64 MB
Internal memory type	DRAM
Mac operating systems supported	macOS
Windows operating systems supported	Windows 7, Windows 8, Windows Vista, Windows XP
Product color	Black
LED indicators	LAN, Power, System, WAN, WLAN
Package depth	254 mm
Package width	190 mm
Package height	60 mm
Package weight	630 g
Cables included	AC, LAN (RJ-45)
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	126 mm
Width	209 mm
Height	26 mm
