TP-Link TL-SC3130G User Manual

13
5.1.4 Audio buttons
Symbols Meaning
)
Note
Speakers turned on
mean the speakers of your computer are
turned on to transmit the sounds from the
connected IP camera(s)
Speakers turned off
Microphone turned on
mean you can broadcast to the connected
IP camera(s) via the Ethernet using your
microphone
Microphone turned off
Volume control bar
5.2 Setting
This function is only for the Administrator. Click this button to get into the Basic and Advance
settings menus.
There are four sub-menus under the BASIC menu, which includes System, Camera, Network,
and Security. For more information, you can refer to Section 6.1、Section 6.2、Section 6.3 and
Section 6.4.
There are six sub-menus under the Advance menu, which includes FTP Client, SMTP, HTTP
event, Schedule, Motion Detection, and System Log. Fore more information, you can refer to
Section 7.1、Section 7.2、Section 7.3、Section 7.4、Section 7.5 and Section 7.6.

TP-Link TL-SC3130G Specifications

General

Maximum resolution	640 x 480 pixels
Supported video modes	-
Video formats supported	M-JPEG, MPEG4
Analog signal format system	NTSC, PAL
Digital zoom	10 x
Optical zoom	- x
Focal length range	4 mm
Audio system	2-way
Built-in microphone	Yes
Dimensions (WxDxH)	58 x 31 x 96 mm
Networking features	Fast Ethernet
Compatible operating systems	Windows 98, ME, 2000, 2003, XP, Vista Mac OS Leapord 10.5
Minimum RAM	512 MB
Minimum processor	Pentium4 1.8GHz
Minimum graphics card memory	64 MB
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Minimum illumination	0.5 lx
Sensor type	CMOS
Optical sensor size	1/4 \
Security algorithms	128-bit WEP, 152-bit WEP, 64-bit WEP, HTTPS, WPA, WPA-PSK, WPA2, WPA2-PSK
Built-in HDD	No
Form factor	Covert
Product color	Black, White
Certification	CE, FCC
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Wi-Fi standards	802.11b, 802.11g
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, DNS, NTP, UPnP, RTSP, RTP, RTCP, HTTP, TCP, UDP, 3GPP/ISMA RTSP
Sustainability certificates	RoHS
