Chapter 8 Appendix
APPENDIX a – FRAME RATE & BIT RATE TABLE
This chapter provides tables that help you to optimize your IP camera with your network environment.
Base on your network upload environment to choose the best Image-Quality setting.
For example, if the network environment is ADSL 256Kb(upload) / 2Mb(download), the most fluent
Image-Quality needs to set up under 256 Kb situation.
A.1 MPEG4 @ 30fps / kbps
Quality 640*480 320*240 160*120
Excellent 1000 300 90
Detailed 400 150 50
Good 300 100 30
Standard 250 70 25
Medium 250 55 20
A.2 MPEG4 / kbps, fps
Image-Size Bitrate Setting
Frame-Rate
Setting
Current Bitrate
Current
Frame-Rate
640*480 2048 30 1800 26
640*480 2048 15 2200 16
640*480 1536 30 1500 30
640*480 1536 15 1700 16
640*480 1024 30 1000 30
640*480 1024 15 1000 16
640*480 512 30 500 30
640*480 512 15 600 16
320*240 1536 30 1500 30
320*240 1536 15 1600 16
320*240 1024 30 1000 30
320*240 1024 15 1000 16
320*240 512 30 550 30

TP-Link TL-SC3130G Specifications

General

Maximum resolution	640 x 480 pixels
Supported video modes	-
Video formats supported	M-JPEG, MPEG4
Analog signal format system	NTSC, PAL
Digital zoom	10 x
Optical zoom	- x
Focal length range	4 mm
Audio system	2-way
Built-in microphone	Yes
Dimensions (WxDxH)	58 x 31 x 96 mm
Networking features	Fast Ethernet
Compatible operating systems	Windows 98, ME, 2000, 2003, XP, Vista Mac OS Leapord 10.5
Minimum RAM	512 MB
Minimum processor	Pentium4 1.8GHz
Minimum graphics card memory	64 MB
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Minimum illumination	0.5 lx
Sensor type	CMOS
Optical sensor size	1/4 \
Security algorithms	128-bit WEP, 152-bit WEP, 64-bit WEP, HTTPS, WPA, WPA-PSK, WPA2, WPA2-PSK
Built-in HDD	No
Form factor	Covert
Product color	Black, White
Certification	CE, FCC
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Wi-Fi standards	802.11b, 802.11g
Cabling technology	10/100Base-T(X)
Supported network protocols	TCP/IP, DHCP, PPPoE, ARP, ICMP, FTP, SMTP, DNS, NTP, UPnP, RTSP, RTP, RTCP, HTTP, TCP, UDP, 3GPP/ISMA RTSP
Sustainability certificates	RoHS
