TP-Link TL-WPA8630P User Manual

TP-LINK TECHNOLOGIES CO., LTD
Building 24 (floors 1, 3, 4, 5), and 28 (floors 1-4) Central Science
and Technology Park, Shennan Rd, Nanshan, Shenzhen, China
TP-LINK TECHNOLOGIES CO., LTD
DECLARATION OF CONFORMITY
For the following equipment:
Product Description: AV1200 Gigabit Passthrough Powerline ac Wi-Fi Extender
Model No.: TL-WPA8630P
Trademark: TP-LINK
We declare under our own responsibility that the above products satisfy all the technical regulations
applicable to the product within the scope of Council Directives:
Directives 2004/108/EC, Directives 2006/95/EC, Directives 2011/65/EU, Directives 1999/5/EC,
Directives 1999/519/EC
The above product is in conformity with the following standards or other normative documents
EN 55022: 2010 + AC: 2011
EN 60950-1: 2006 + A11: 2009 + A1: 2010 + A12: 2011 +A2: 2013
EN 50412-2-1: 2005
EN 62311: 2008
EN 300 328 V1.8.1
EN 301 489-1 V1.9.2 & EN 301 489-17 V2.2.1
The product carries the CE Mark:
Person responsible for making this declaration:
Yang Hongliang
Product Manager of International Business Date of issue: 2016-03-29

TP-Link TL-WPA8630P Specifications

General

Modulation	OFDM
Power plug	Type F
Ethernet LAN	Yes
Wi-Fi standards	802.11a, Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n)
PowerLine standard	HomePlug AV2
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES
Networking standards	IEEE 1901, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN (RJ-45) ports	3
Maximum data transfer rate	1300 Mbit/s
Maximum operating distance	300 m
Ethernet LAN interface type	Gigabit Ethernet
Power consumption (standby)	7 W
Power consumption (typical)	11 W
Product color	White
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package type	Box
Quantity per pack	1 pc(s)
Harmonized System (HS) code	85171800

Weight and Dimensions

Depth	75 mm
Width	42 mm
Height	152 mm
