Table 7. Point weights, units with InvisiSound standard or superior option - I-P (lb) (continued)
Unit
Size
Point Weights (lb)
1 2 3 4 5 6 7 8 9 10
225 1966 1882 2000 1896 1911 1928 1595 1816 113 135
250 2014 1939 2069 1964 1972 1981 1609 1827 111 133
275 1942 1845 1913 1790 1839 1812 1832 2023 870 954
300 1991 1934 2137 2038 2151 2104 1951 2053 741 862
Extended Length Units
150 2268 2021 2036 1850 1687 1881 739 1008
165 2181 1966 2115 2006 2139 2390 768 965
180 2147 1936 2181 2041 2224 2574 771 977
200 2583 2375 2157 2083 1843 2047 736 861 610 693
225 2806 2479 2418 2266 2040 2311 785 969 610 741
250 2844 2519 2497 2342 2112 2384 801 982 597 723
275 2699 2394 2417 2282 2297 2538 994 1204 1013 1133
300 2888 2488 2575 2374 2093 2281 1820 2090 708 802
Table 8. Point weights, units with InvisiSound standard or superior option - SI (kg)
Unit
Size
Point Weight (kg)
1 2 3 4 5 6 7 8 9 10
Standard Length Units
150 824 730 753 670 688 719 332 423
165 794 775 775 749 791 802 427 499
180 804 797 790 781 808 836 432 510
200 806 827 791 749 777 770 681 742 57 62
225 892 854 907 860 867 874 723 824 51 61
250 913 879 938 891 894 898 730 828 51 60
275 881 837 868 812 834 822 831 917 395 433
300 903 877 969 924 976 954 885 931 336 391
Extended Length Units
150 1029 916 923 839 765 853 335 457
165 989 892 959 910 970 1084 348 437
180 974 878 989 926 1009 1167 350 443
200 1172 1077 978 945 836 928 334 390 277 314
225 1272 1124 1097 1028 925 1048 356 439 277 336
250 1290 1142 1132 1062 958 1081 363 445 271 328
275 1224 1086 1096 1035 1042 1151 451 546 459 514
300 1310 1128 1168 1077 949 1034 825 948 321 364
Table 9. Point weights, units with InvisiSound ultimate option - I-P (lb)
Unit
Size
Point Weights (lb)
1 2 3 4 5 6 7 8 9 10
Standard Length Units
150 1818 1609 1861 1678 1716 1786 731 932
165 1752 1710 1909 1852 1944 1968 941 1099
