AC-SVX001A-EN
29
Table 9. Point weights, units with InvisiSound ultimate option - I-P (lb) (continued)
Unit
Size
Point Weights (lb)
1 2 3 4 5 6 7 8 9 10
180 1774 1757 1941 1923 1981 2044 952 1124
200 1777 1823 1944 1851 1914 1898 1501 1636 126 136
225 1966 1882 2200 2096 2111 2128 1595 1816 113 135
250 2014 1939 2269 2164 2172 2181 1609 1827 111 133
275 1942 1845 2113 1990 2039 2012 1832 2023 870 954
300 1991 1934 2337 2238 2351 2304 1951 2053 741 862
Extended Length Units
150 2268 2021 2236 2050 1887 2081 739 1008
165 2181 1966 2315 2206 2339 2590 768 965
180 2147 1936 2381 2241 2424 2774 771 977
200 2583 2375 2357 2283 2043 2247 736 861 610 693
225 2806 2479 2618 2466 2240 2511 785 969 610 741
250 2844 2519 2697 2542 2312 2584 801 982 597 723
275 2699 2394 2617 2482 2497 2738 994 1204 1013 1133
300 2888 2488 2775 2574 2293 2481 1820 2090 708 802
Table 10. Point weights, units with InvisiSound ultimate option - SI (kg)
Unit
Size
Point Weight (kg)
1 2 3 4 5 6 7 8 9 10
Standard Length Units
150 824 730 844 761 778 810 332 423
165 794 775 866 840 882 892 427 499
180 804 797 880 872 899 927 432 510
200 806 827 881 839 868 861 681 742 57 62
225 892 854 998 950 957 965 723 824 51 61
250 913 879 1029 981 985 989 730 828 51 60
275 881 837 958 903 925 912 831 917 395 433
300 903 877 1060 1015 1066 1045 885 931 336 391
Extended Length Units
150 1029 916 1014 930 856 944 335 457
165 989 892 1050 1000 1061 1175 348 437
180 974 878 1080 1016 1099 1258 350 443
200 1172 1077 1069 1035 926 1019 334 390 277 314
225 1272 1124 1187 1118 1016 1139 356 439 277 336
250 1290 1142 1223 1153 1049 1172 363 445 271 328
275 1224 1086 1187 1126 1133 1242 451 546 459 514
300 1310 1128 1259 1167 1040 1125 825 948 321 364
Isolator Selections
See Dimensions and Weights chapter for isolator
mounting position dimensions.
IInnssttaallllaattiioonn MMeecchhaanniiccaall
