Electrical Data
76 WSHP-SVX01L-EN
Table 46. Electrical data - ECM motors - 1½-6 tons
Model
No. Volts
Total
Unit
FLA
Comp
RLA
(ea)
Comp
LRA
(ea)
No. of
Comp.
Cmp
MCC
Blower
Motor
FLA
Blower
Motor
hp
Fan
Motor
Num.
Minimum
Circuit
Ampacity
Maximum
Overcurrent
Protective
Device
Electric
Heat
kW
Electric
Heat
Amps
EXH/EXV
018 208/60/1 11.1 9.6 42.0 1 13.4 1.50 1/2 1 13.50 20 0.0 0.0
018 208/60/1 13.3 9.6 42.0 1 13.4 1.50 1/2 1 16.66 20 2.5 11.8
018 230/60/1 11.1 9.6 42.0 1 13.4 1.50 1/2 1 13.50 20 0.0 0.0
018 230/60/1 14.5 9.6 42.0 1 13.4 1.50 1/2 1 18.18 20 3.0 13.0
018 265/60/1 9.0 7.7 35.0 1 10.8 1.30 1/2 1 10.93 15 0.0 0.0
018 265/60/1 16.4 7.7 35.0 1 10.8 1.30 1/2 1 20.49 25 4.0 15.1
EXH/EXV
024 208/60/1 15.7 13.5 58.3 1 21.0 2.20 1/2 1 19.08 30 0.0 0.0
024 208/60/1 17.9 13.5 58.3 1 21.0 2.20 1/2 1 22.34 30 3.3 15.7
024 230/60/1 15.7 13.5 58.3 1 21.0 2.20 1/2 1 19.08 30 0.0 0.0
024 230/60/1 19.6 13.5 58.3 1 21.0 2.20 1/2 1 24.49 30 4.0 17.4
024 265/60/1 10.1 9.0 54.0 1 14.0 1.10 1/2 1 12.35 20 0.0 0.0
024 265/60/1 21.1 9.0 54.0 1 14.0 1.10 1/2 1 26.38 30 5.3 20.0
030 208/60/1 17.3 14.1 77.0 1 22.0 3.20 1/2 1 20.83 30 0.0 0.0
030 208/60/1 26.8 14.1 77.0 1 22.0 3.20 1/2 1 33.45 35 4.9 23.6
030 230/60/1 17.3 14.1 77.0 1 22.0 3.20 1/2 1 20.83 30 0.0 0.0
030 230/60/1 29.3 14.1 77.0 1 22.0 3.20 1/2 1 36.61 40 6.0 26.1
030 265/60/1 13.7 10.9 60.0 1 17.0 2.80 1/2 1 16.43 25 0.0 0.0
030 265/60/1 32.8 10.9 60.0 1 17.0 2.80 1/2 1 41.00 45 8.0 30.0
036 208/60/1 18.1 14.1 77.0 1 22.0 4.00 3/4 1 21.63 35 0.0 0.0
036 208/60/1 27.6 14.1 77.0 1 22.0 4.00 3/4 1 34.45 35 4.9 23.6
036 230/60/1 18.1 14.1 77.0 1 22.0 4.00 3/4 1 21.63 35 0.0 0.0
036 230/60/1 30.1 14.1 77.0 1 22.0 4.00 3/4 1 37.61 40 6.0 26.1
036 265/60/1 15.7 12.2 72.0 1 19.0 3.50 3/4 1 18.75 30 0.0 0.0
036 265/60/1 33.5 12.2 72.0 1 19.0 3.50 3/4 1 41.88 45 8.0 30.0
036 208/60/3 13.0 9.0 71.0 1 14.0 4.00 3/4 1 15.25 20 0.0 0.0
036 208/60/3 17.6 9.0 71.0 1 14.0 4.00 3/4 1 22.00 25 4.9 13.6
036 230/60/3 13.0 9.0 71.0 1 14.0 4.00 3/4 1 15.25 20 0.0 0.0
036 230/60/3 19.1 9.0 71.0 1 14.0 4.00 3/4 1 23.83 25 6.0 15.1
036 460/60/3 9.1 5.6 38.0 1 8.8 3.50 3/4 1 10.50 15 0.0 0.0
036 460/60/3 13.5 5.6 38.0 1 8.8 3.50 3/4 1 16.85 20 8.0 10.0
042 208/60/1 22.3 17.9 112.0 1 28.0 4.40 3/4 1 26.78 40 0.0 0.0
042 208/60/1 35.7 17.9 112.0 1 28.0 4.40 3/4 1 44.56 45 6.5 31.3
042 230/60/1 22.3 17.9 112.0 1 28.0 4.40 3/4 1 26.78 40 0.0 0.0
042 230/60/1 39.2 17.9 112.0 1 28.0 4.40 3/4 1 48.98 50 8.0 34.8
042 208/60/3 17.6 13.2 88.0 1 20.6 4.40 3/4 1 20.90 30 0.0 0.0
042 208/60/3 22.4 13.2 88.0 1 20.6 4.40 3/4 1 28.05 30 6.5 18.0
042 230/60/3 17.6 13.2 88.0 1 20.6 4.40 3/4 1 20.90 30 0.0 0.0
042 230/60/3 24.5 13.2 88.0 1 20.6 4.40 3/4 1 30.60 35 8.0 20.1
042 460/60/3 9.8 6.0 44.0 1 9.3 3.80 3/4 1 11.30 15 0.0 0.0
042 460/60/3 17.1 6.0 44.0 1 9.3 3.80 3/4 1 21.38 25 10.6 13.3
048 208/60/1 25.0 19.9 109.0 1 31.0 5.10 3/4 1 29.98 45 0.0 0.0
048 208/60/1 36.4 19.9 109.0 1 31.0 5.10 3/4 1 45.44 50 6.5 31.3
