Trane EXHF User Manual

General Information
WSHP-SVX01L-EN 9
Table 2. Refrigerant charge
Unit
(60 Hz)
Heat Pump Heat Pump w/HGRH
Catalog
Net Btuh Circuit 1
(a)
Circuit 2
(a)
Circuit 1
(a)
Circuit 2
(a)
GEHE006
7500 25.3 — 26.8 —
GEHE009
8800 26.0 — 27.5 —
GEHE012
11700 28.5 — 30.5 —
GEHE015
14300 29.0 — 30.5 —
GEHE018
18000 36.0 — 39.0 —
GEHE024
24000 38.5 — 41.5 —
GEHE030
28200 42.5 — 45.0 —
GEHE036
35200 47.0 — 50.5 —
GEHE042
41500 55.0 — 58.5 —
GEHE048
49700 62.0 — 66.5 —
GEHE060
59700 66.0 — 70.5 —
GEHE072
73300 67.0 67.0 71.0 67.0
GEHE090
88100 64.0 64.0 68.0 64.0
GEHE120
115900 93.0 93.0 97.0 93.0
GEHE150
152800 136.0 136.0 144.0 136.0
GEHE180
180800 126.0 126.0 134.0 126.0
GEVE006
7600 25.7 — 27.2 —
GEVE009
8800 26.5 — 28.5 —
GEVE012
11600 29.5 — 31.5 —
GEVE015
14400 27.5 — 29.5 —
GEVE018
17800 37.0 — 40.0 —
GEVE024
24700 38.0 — 40.5 —
GEVE030
28800 43.5 — 46.0 —
GEVE032
30900 50.0 — — —
GEVE036
36300 49.5 — 53.0 —
GEVE040
40200 48.5 — — —
GEVE042
41000 55.5 — 59.0 —
GEVE048
49500 64.0 — 69.0 —
GEVE060
61600 68.5 — 74.0 —
GEVE072
74900 64.0 64.0 68.0 64.0
GEVE090
89700 82.0 78.0 86.0 78.0
GEVE120
119300 98.0 102.0 102.0 102.0
GEVE150
154300 122.0 122.0 130.0 122.0
GEVE180
185700 128.0 128.0 136.0 128.0
GEVE240
249800 284.0 284.0 292.0 287.0
GEVE300
305700 260.0 260.0 268.0 260.0
(a) Ounces of refrigerant
