Table 2. SCWF/SIWF Water-cooled self-contained, 46-110 tons (continued)
Unit Size 46 52 58 65 72 80 90 100 110
Refrigerant
Charge — lbs. R-
410A (Standard
Capacity/High
Capacity)
Circuit A
24.5/28.5
21.0
26.5/
31.5
22.0 24.5 28.0 24.5 24.5 24.5
Circuit B
24.5/28.5
21.0
26.5/
31.5
22.0 24.5 28.0 24.5 24.5 24.5
Circuit C
24.5/28.5
21.0
26.5/
31.5
22.0 24.5 28.0 24.5 24.5 24.5
Circuit D
N/A N/A N/A
21.0 22.0 28.0 24.5 24.5 24.5
Circuit E
N/A N/A N/A N/A N/A N/A
24.5 24.5 24.5
Circuit F
N/A N/A N/A N/A N/A N/A N/A
24.5 24.5
Capacity Steps - %
100/70/41/30/
0
100/65/
32/0
100/65/
30/0
100/71/
44/24/0
100/71/
43/23/0
100/73/
46/20/0
100/80/
40/20/0
100/75/
38/19/0
100/66/
33/17/0
Notes:
1. Compressors are Trane 3-Dâ„¢ scroll.
2. All units operate with R-410A. Units ships with full operating charge.
3. Maximum cfm limits are set to prevent moisture carryover on the evaporator coil.
4. Minimum cfm limits are set to ensure stable thermal expansion valve operation at low load conditions.
Table 3. SCRF/SIRF Air-cooled self-contained
Unit Size 25 29 30 35 40 50 60
Compressor Data
Quantity
1/1 1/1
3 3
2/1
3 4
Nominal Ton/Comp
15/10 15/10
10 10
10/15
15 15
Circuits 2 2 2 2 2 2 2
Evaporator Coil Data
Rows 4 4 3 4 4 4 6
Sq. Ft.
29.98 29.98 31.35 31.35 38.57 49.09 49.09
FPF 144 144 120 144 144 144 144
Evaporator Fan Data
Quantity
1 1 1 1 1 1 1
Size (Dia.)
18" 18" 20" 20" 25" 25" 27.5"
Minimum HP 5 5 5 5 7.5 7.5 10
Minimum kW
(3.73) (3.73) (3.73) (3.73) (5.59) (5.59) (7.46)
Maximum HP 20 20 25 25 30 40 50
Maximum kW
(18.64) (18.64) (18.64) (18.64) (22.37) (29.84) (37.29)
Minimum Design CFM
8700 8700 9100 9880 11960 15080 20800
Maximum Design CFM
12325 13600 14875 16150 19550 24650 29800
Refrigerant Charge
See Note 2 below
Capacity Steps - %
100/62/39/0 100/59/39/0 100/65/31/0 100/65/30/0
100/70/41/
30/0
100/65/30/0
100/73/46/
20/0
