SS-SVX11K-EN
107
Preliminary Expansion Valve
Adjustment
NNOOTTIICCEE
CCoommpprreessssoorr DDaammaaggee!!
FFaaiilluurree ttoo ffoollllooww iinnssttrruuccttiioonnss ccoouulldd rreessuulltt iinn
ccoommpprreessssoorr ffaaiilluurree oorr rreedduucceedd ccoommpprreessssoorr lliiffee..
IInnccrreeaassee tthheerrmmaall eexxppaannssiioonn vvaallvvee ssuuppeerrhheeaatt
sseettttiinnggss bbeeffoorree ssttaarrttiinngg ccoommpprreessssoorrss ttoo mmiinniimmiizzee
ccoommpprreessssoorr ooppeerraattiioonn wwiitthh llooww ooiill vviissccoossiittyy..
No bleed thermal expansion valves are set by
manufacturers to control between 12-14.4°F superheat
leaving the evaporator at nominal design conditions.
Thermal expansion valves with bleeds are set to their
highest superheat setting. Actual superheat depends
on many factors (valve vs. system relative sizing,
operating conditions, system load step, system charge,
piping, and condenser fan control). The thermal
expansion valves must be adjusted as part of the unit
start-up procedure. Do not adjust valves beyond
manufacturer's available nominal adjustment range.
NNoottee:: In tables below, valve part numbers with “-ZGA”
in place of “-GA”, may be used interchangeably.
“ERZE-” part number valves are an acceptable
alternate to “BBIZE” valves.
Table 30. Thermal expansion valve manufacturer settings - no bleed — Sporlan
Standard off the shelf nominal valve settings (90 PSIG air test setting)
Valve
Superheat,
°F
CW turns
available
CCW turns
available
Superheat
change per
turn
Field adjust
for 18°F (DX
evap coil)
Field adjust for
15°F (EVP only)
BBIZE-1-GA
12
4.5
4.5
2.4°F 2.5 CW —
BBIZE-1-1/2-GA
BBIZE-2-GA
BBIZE-3-GA
BBIZE-4-GA
BBIZE-5-GA
BBIZE-6-GA
BBIZE-8-GA
BBIZE-12.5-GA
BBIZE-15-GA
OZE-20-GA
3.4°F .25 CW .25 CWOZE-25-GA
OZE-35-GA
OZE-50-GA
7.5 1.8°F 3.25 CW 1.75 CW
OZE-60-GA
Table 31. Thermal expansion valve manufacturer settings - no bleed — Emerson
Standard off the shelf nominal valve settings
Valve Nom Tons
Super-
heat, °F
CW turns
available
CCW turns
available
Superheat
change per
turn
Field adjust
for 18°F (DX
evap coil)
Field adjust
for 15°F
(EVP only)
C
1-1/2 to 7
13
6 6 4 1.25 CW
TF 12 to 20 5 5 2 2.5 CW 1.0 CW
SSttaarrtt--UUpp
