Trane Tracer TD-5 User Manual

Reports
RT-SVX49C-EN 23
Binary Input Report
The Binary Input report provides general Reliatel Unit
operating information. Touch the Binary Input Report
button to view the Binary Input Report screen.
Data Area
The following data appear in the Configuration Report
screen.
Table 8. Binary input report - data area
RTRM
Emergency Stop Input
Auto, Emergency Stop
Occupancy
Occupied, Unoccupied
RTRM Fan Proving Input
Closed, Open
RTRM
Thermostat Y1 Input
Open, Closed
Thermostat W1/O Input
Open, Closed
Thermostat G Input
Open, Closed
RTRM
Thermostat W2 Input
Open, Closed
Thermostat Y2 Input
Open, Closed
Thermostat X2 Input
Open, Closed
RTRM
Compressor 1 Disable Input
Enabled, Disabled
Compressor 1 Proving Input
Open, Closed
RTRM
Compressor 2 Disable Input
Enabled, Disabled
Compressor 2 Proving Input
Open, Closed
RTOM
Supply Fan Proving Input
Open, Closed
Condensate Drain Overflow Input
Open, Closed
RTOM
Ventilation Override Pressurize Input
Open, Closed
Ventilation Override Purge Input
Open, Closed
Ventilation Override Exhaust Input
Open, Closed
RTOM
Frostat™ Input
Open, Closed
Clogged Filter Input
Open, Closed
RTOM
Freezestat Input
Open, Closed
Smoke Detector Input
Open, Closed
RTOM
Reheat Humidistat Input
Open, Closed
Changeover Switch Input
Cooling, Heating
VSM
Compressor 3 Disable Input
Enabled, Disabled
Compressor 3 Proving Input
Open, Closed
RTVM
Exhaust Fan Proving Input
Open, Closed
Reheat LPC Input
Enabled, Disabled
IGN
IGN Pressure Switch Input
Open, Closed
IGN Temp Limit Input
Open, Closed
IGN Flame Rollout Input
Open, Closed
Binary Output Report
The Binary Input report provides general Reliatel Unit
operating information. Touch the Binary Input Report
button to view the Binary Input Report screen.
Data Area
The following data appears in the Configuration Report
screen.
Table 9. Binary output report - data area
RTRM
Supply Fan Output
Off, On
Compressor 1 Output
Off, On
Compressor 2 Output
Off, On
RTRM
Heat Stage 1 Output
Active, Inactive
SOV 1 Output
Active, Inactive
Outdoor Fan A Output
Energized, De-energized
RTRM
Heat Stage 2 Output
Active, Inactive
SOV 2 Output
Active, Inactive
Outdoor Fan B Output
Energized, De-Energized
RTOM/RTAM/RTVM/
RTEM/RTDM
RTOM Low Fan Speed Output
Off, On
Alarm Indicator Output
Off, On
VAV Box Output
Off, On
RTOM/RTAM/RTVM/
RTEM/RTDM
Power Exhaust Fan Output
De-energized, Energized
Reheat Pumpout Relay
Off, On
IGN
IGN Inducer High Output
Off, On
IGN Inducer Low Output
Off, On
