Figure 22. Setup screen
Settings
32 RT-SVX49C-EN
This Setup screen shows a list of the setup items in button
format. The available setup items are listed below:
Unit Mode
Heat, Cool, Auto
Supply Fan Mode
On, Auto
Emergency Heat Mode Request
Auto, Emergency Heat
System Control Mode
Local, Remote
Display Read Only Mode
Read, Write
Supply Air Reset Type
Heat, Cool, Auto
Display Settings Screen
The selections in this category contain settings that affect
the way in which information is displayed on all of the TD-
5 display screens. From each screen, the current settings
can be viewed. To change a setting, touch the preferred
value.
Display Preferences
Touch the Display Preferences button to open the
associated screen (Figure 23, p. 33). On this screen, all
available
options to display information on the TD-5
screens are available. There are two pages on this screen,
accessed by using the arrow button at the bottom of the
screen.
