Settings
RT-SVX49C-EN 31
Data Area
The following data appears in the Setpoints screen.
Front Panel Occupied Space Cooling Setpoint
XXX.X °F/C
Front Panel Unoccupied Space Cooling Setpoint
XXX.X °F/C
Space Dehumidification Setpoint
XX%
Front Panel Occupied Space Heating Setpoint
XXX.X °F/C
Front Panel Unoccupied Space Heating Setpoint
XXX.X °F/C
Supply Air Reheat Setpoint
XXX.X °F/C
Discharge Air Heating Setpoint
XXX.X °F/C
Discharge Air Cooling Setpoint
XXX.X °F/C
Duct Static Pressure Setpoint
XXX.X °F/C
Duct Static Pressure Deadband
X.XX iwc
Morning Warm up Setpoint
XXX.X °F/C
Supply Air Cooling Setpoint
XXX.X °F/C
Supply Air Heating Setpoint
XXX.X °F/C
Daytime Warm-Up Initiate Setpoint
XXX.X °F/C
Space Pressure Setpoint
X.XX iwc
Space Pressure Deadband
XXX.X °F/C
Daytime Warm up Terminate Setpoint
XXX.X °F/C
CO
2
Upper Limit Setpoint
XXXX PPM
CO
2
Lower Limit Setpoint
XXXX PPM
Outdoor Air Flow Adjustment Setpoint
X.XX
Supply Air Reset Setpoint
XXX.X °F/C
Supply Air Reset Amount
XXX.X °F/C
Supply Fan Adjustment Setpoint
XX%
Econ Reference Enthalpy Setpoint
XX.X BTU/lb
Econ Dry Bulb Enable S
etpoint
XXX.X °F/C
Exhaust Fan Enable Setpoint
XX%
Design Min OA flow Setpoint
XXXXX cfm
DCV Min OA Flow Setpoint
XXXX cfm
Min OA Flow Deadband
XXXXX cfm
Design Min OA Damper Pos Setpoint 100% Fan
XX%
Design Min OA Damper Pos Setpoint Mid Fan
XX%
Design Min OA Damper Pos Setpoint Min Fan
XX%
DCV Min OA Damper Pos Setpoint 100% Fan
XX%
DCV Min OA Damper Pos Setpoint Min Fan
XX%
Front Panel Dehumid Override Cool Setpoint
XXX.X °F/C
Front Panel Dehumid OVerride Heat Setpoint
XXX.X °F/C
Compressor 1 Starts
XXXXXX
Compressor 2 Starts
XXXXXX
Compressor 3 Starts
XXXXXX
Compressor 1 Starts Running Time
HHHHHH:MM
Compressor 2 Starts Running Time
HHHHHH:MM
Compressor 3 Starts Running Time
HHHHHH:MM
Outdoor Fan A Starts
XXXXXX
Outdoor Fan B Starts
XXXXXX
Variable Speed Outdoor Fan Starts
XXXXXX
Outdoor Fan A Running Time
HHHHHH:MM
Outdoor Fan B Running Time
HHHHHH:MM
Variable Speed Outdoor Fan Running Time
HHHHHH:MM
Supply Fan Starts
XXXXX
Supply Fan Running Time
HHHHH:MM
Exhaust Fan Starts
XXXXXX
Exhaust Fan Running Time
HHHHH:MM
Setup
Touch the Setup button to view the Setpoints screen.
Touch the arrow buttons to move between screens.
