Trane Tracer TD-5 User Manual

Graphs
RT-SVX49C-EN 29
VAV System:
The table below describes the data in the System Status
graph:
Data Point Line Color Axis
Active Supply Air Temp Setpoint Pink Left
Active Space Temp Green Left
Supply Air Temp Black Left
Return Air Temp Red Left
Economizer Graph:
The table below describes the data in the graph:
Data Point Line Color Axis
Outdoor Air Temp Purple Left
Mixed Air Temp Grey Left
Active Min OA Damper Position Target Pink Right
Outdoor Air Damper % Yellow Right
Outside Air Ventilation:
The table below describes the data in the graph:
Data Point Line Color Axis
Min Outdoor Air Flow Target Black Left
Outdoor Air Flow Pink Left
Outdoor Air Damper % Yellow Right
Outdoor Air Temp Purple Right
CO
2
Graph:
The table below describes the data in the graph:
Data Point Line Color Axis
Active Upper CO
2
Limit Setpoint Red Left
Active Lower CO
2
Limit Setpoint Black Left
Space CO
2
Green Left
Outdoor Air Damper % Yellow Right
Humidity Graph:
The table below describes the data in the graph:
Data Point Line Color Axis
Space Dehumidification Setpoint Yellow Left
Outdoor Air Humidity Red Left
Return Air Humidity Black Left
Space Humidity Green Left
Heat Pump Graph:
The table below describes the data in the graph:
Data Point Line Color Axis
Outdoor Coil Temp Ckt 1 Green Left
Outdoor Coil Temp Ckt 2 Blue Left
Outdoor Air Temp Purple Left
Discharge Air Temperature Grey Left
Active Cooling Stages Blue Right
