88
Maintenance and Adjustment
Brakes
Brake Wear Inspection
1. Brake pads
2. Minimum thickness line
Brake pads must be inspected in accordance
with scheduled requirements and replaced if
worn to, or beyond the minimum service
thickness.
On Daytona 675, Street Triple and Street
Triple R, if the lining thickness of any pad
(front or rear brakes) is less than 1.5 mm
(0.06 in), that is, if the pad has worn down to
the bottom of the grooves, replace all the
pads on the wheel. On Daytona 675 R, the
minimum thickness of any front brake pad is
1.0 mm (0.04 in) though for the rear pads it
remains at 1.5 mm (0.06 in).
Brake pads for this model supplied by
Triumph will have the carrier plate at least
4.5 mm thick. Always have replacement
brake pads supplied and installed by your
Triumph dealer.
1. Carrier plate
2. Brake pad
cbmz
1
2
Warning
If installing new proprietary brand brake
pads, check that the carrier plate of the
brake pad is at least 4.5 mm thick.
Installing brake pads with the carrier plate
less than 4.5 mm thick may result in brake
failure due to the possible loss of the brake
pad as it wears.
cezg_1
1
4.5 mm
2
