sensitivity.

4.1.3 Serial Comm.

Options Parameters Default

Baud Rate 1200 bps/ 2400 bps/ 4800 bps/ 9600 bps

/ 19200 bps/ 38400 bps/ 57600 bps/

115200 bps

9600 bps

Parity None/ Odd/ Even None

Data Bits 7 Data Bits/ 8 Data Bits 8 Data Bits

Stop Bits 1 Stop Bit/ 2 Stop Bits 1 Stop Bit

4.1.3.1 Baud Rate:

This option is used to set the RS-232 baud rate, and the default setting is

9600 bps.

Press button under ª and © icon to select the different baud rate, and

press button under “V” icon to set the value into printer. When you enter

this list, the baud rate value in the right side of ¨ icon is current setting in the

printer.

4.1.3.2 Parity:

Calibrate

100

+ - V

Baud Rate - Parity - Data Bite - Stop Bits - Exit

¨9600 bps

19200 bps

ª © V

None

¨Odd

ª © V

Serial Comm.
