TSC TTP-2410MT Series Service Manual

13
13
3. MECHANISM
3.1 Remove Covers and the Lower Front Panel
1. Remove two screws on rear of printer.
2. Open printer right side cover and remove two screws then close the cover.
3. Push the printer left side electronics cover toward the interface direction then take it out
from the printer. Please refer to the following pictures.
Screws
Screws
