TSC TTP-2410MT Series Service Manual

18
18
3.3 Replacing the Power Supply Unit
1. Refer to section 3.1 to remove the electronics cover.
2. Disconnect all connectors on the power supply unit.
3. Remove 2 screws and 2 cable ties.
---- Connector
---- Screw
4. Remove/Replace the power supply unit.
5. Reassemble the parts in the reverse procedures.
